The iconic Jeep, a symbol of rugged adventure and off-road capability, has housed a variety of transmissions throughout its storied history. Among them, the BorgWarner T5 manual transmission holds a significant, albeit sometimes debated, place. If you’re a Jeep enthusiast restoring a classic YJ Wrangler, maintaining an early XJ Cherokee, or simply seeking a cost-effective replacement for your existing T5, understanding this transmission is crucial. This comprehensive guide will delve into everything you need to know about the T5 Jeep transmission for sale, from its specifications and benefits to where to find one and how to ensure its longevity.

Understanding the T5 Transmission: A Brief Overview

T5 Jeep Transmission For Sale: Your Comprehensive Guide to Finding, Buying, and Maintaining This Classic Gearbox

The T5 is a 5-speed manual transmission manufactured by BorgWarner, widely adopted by various automakers, including AMC (and by extension, Jeep) during the 1980s and early 1990s. Its widespread use in Jeeps primarily includes the 1987-1995 YJ Wrangler, some late-model CJ-7s, and select early XJ Cherokee and MJ Comanche models. It was typically paired with the AMC 2.5L 4-cylinder and the 4.2L (258 cubic inch) 6-cylinder engines.

Characterized by its aluminum case, the T5 is relatively lightweight, contributing to easier handling and a slightly better power-to-weight ratio compared to heavier iron-cased transmissions. While generally considered a light to medium-duty transmission, its performance varies significantly between its two main versions:

• Non-World Class (NWC) T5: These earlier versions, common in many Jeep applications, use bronze synchronizer rings and primarily roller bearings. They are generally less robust than their World Class counterparts.
• World Class (WC) T5: Introduced later, the WC T5 features a more durable design with fiber-lined synchronizer rings, tapered roller bearings on the main shaft, and a different internal oiling system. These enhancements significantly improve shifting feel and power handling capabilities, making them the preferred choice for performance and longevity.

Identifying which version you have or are looking at is paramount, as it directly impacts the transmission’s durability and the type of fluid it requires.

Why Choose a T5 Jeep Transmission? Benefits and Ideal Use Cases

Despite its reputation for being less robust than its successors like the AX-15 or NV3550, the T5 still offers compelling reasons for consideration, especially for specific applications:

1. Cost-Effectiveness: T5 transmissions are generally more affordable on the used market than later Jeep manual transmissions. This makes them an attractive option for budget-conscious repairs or restorations.
2. Availability: Due to their widespread use, T5 units can still be found in salvage yards, online marketplaces, and from private sellers, though their numbers are dwindling.
3. Lightweight Construction: The aluminum casing makes the T5 lighter, which can be a minor advantage for overall vehicle weight.



4. Direct Fit for Original Applications: For owners of Jeeps originally equipped with a T5, a replacement unit offers a straightforward, bolt-in solution, requiring no modifications to the bellhousing, transfer case adapter, or driveshafts.
5. Restoration Accuracy: For purists restoring a classic YJ or CJ to original specifications, retaining the factory T5 is essential for authenticity.
6. Mild Driving and Off-Roading: For daily drivers, light trail use, or Jeeps with stock tire sizes and gearing, a well-maintained T5 (especially a WC version) can perform admirably. It’s not designed for aggressive rock crawling or extreme off-roading, but it handles typical light-duty Jeep tasks effectively.

Finding a T5 Jeep Transmission For Sale: Where to Look

The search for a T5 Jeep transmission can be an adventure in itself. Here are the most common avenues to explore:

• Salvage Yards/Junkyards: Often the first stop for used parts, salvage yards can yield hidden gems. Look for Jeeps from the late 80s to mid-90s. Be prepared to inspect the transmission on-site (look for leaks, check input/output shafts).
• Online Marketplaces: Websites like eBay, Craigslist, and Facebook Marketplace are goldmines for private sellers. Search broadly for "T5 Jeep transmission," "YJ transmission," or "CJ T5." Be cautious of "too good to be true" deals and always ask for detailed photos and videos.
• Dedicated Jeep Forums and Social Media Groups: Many active Jeep communities have "for sale" sections or groups where members buy, sell, and trade parts. These often offer the advantage of dealing with fellow enthusiasts who might provide more accurate descriptions and helpful advice.
• Specialty Jeep Parts Dealers: While less common for used T5s, some specialized shops or transmission rebuilders might offer rebuilt units with a warranty. This is often the most expensive option but provides peace of mind.
• Transmission Rebuilders: If you find a cheap core (a non-functional unit) or have a failing T5, a professional transmission rebuilder can often bring it back to life. This allows you to potentially upgrade to WC specifications if starting with an NWC core, or simply ensure all worn components are replaced.

Important Considerations Before Buying a T5 Jeep Transmission

Purchasing a used transmission, especially one as venerable as the T5, requires careful consideration. Here’s what to keep in mind:

• Condition Assessment:
  • Visual Inspection: Look for cracks in the casing, severe leaks, or obvious damage.
  • Input/Output Shaft Play: Excessive play can indicate worn bearings.
  • Shifter Action (if possible): If still in the vehicle, check if it shifts smoothly through all gears without grinding.
  • Fluid Condition: If you can drain or check the fluid, look for metallic particles, which indicate internal wear.
• World Class (WC) vs. Non-World Class (NWC) Identification: This is critical.
  • Case Casting: WC cases often have "WC" cast into the casing, or sometimes a "13-52" (BorgWarner model number for T5) followed by a "1" or "2" for WC. NWC usually has "13-52-0XX."
  • Front Input Bearing Retainer: WC versions often have a larger, wider input bearing retainer that is flush with the front of the case, while NWC versions have a smaller, recessed retainer.
  • Fluid Type: WC T5s typically use ATF (Dextron/Mercon), while NWC T5s use GL-4 manual transmission fluid. If the seller knows the fluid type, it’s a strong clue.
• Compatibility:
  • Bellhousing Bolt Pattern: Ensure the T5 you’re buying has the correct bolt pattern for your AMC engine (2.5L or 4.2L). There are also Ford and GM pattern T5s, which will not work without adapters.
  • Input Shaft Length and Spline Count: The T5 used in Jeeps typically has a 10-spline input shaft. Ensure the length matches your clutch and pilot bearing setup.
  • Output Shaft/Tailshaft: Verify the output shaft spline count and design match your transfer case (e.g., NP231, NP207). Jeep T5s usually have a 21-spline output shaft.
• Warranty/Return Policy: If buying from a rebuilder or a reputable used parts dealer, inquire about any warranty or return policy. Private sales usually come with no guarantees.
• Shipping Costs: Transmissions are heavy. Factor in significant shipping costs if buying from a distant seller. Local pickup is always preferred.

Installation and Maintenance Tips for Your T5 Jeep Transmission

Once you’ve acquired your T5, proper installation and ongoing maintenance are key to its longevity.

• Pre-Installation Checks:
  • New Clutch Kit: Always install a new clutch, pressure plate, and throw-out bearing with a "new" transmission.
  • Pilot Bearing/Bushing: Replace the pilot bearing/bushing in the crankshaft.
  • Rear Main Seal: Consider replacing the engine’s rear main seal while the transmission is out.
  • Transmission Mount: Inspect and replace the transmission mount if it’s worn or cracked.
  • Bellhousing Alignment: Ensure the bellhousing is properly aligned with the engine block to prevent premature bearing wear.
• Fluid Type and Level: This cannot be stressed enough. Use the correct fluid.
  • World Class (WC) T5: Typically uses Dexron/Mercon Automatic Transmission Fluid (ATF).
  • Non-World Class (NWC) T5: Requires GL-4 rated manual transmission fluid. NEVER use GL-5 fluid in an NWC T5, as the sulfur-phosphorous additives in GL-5 can corrode the brass synchronizers.
  • Fill to the bottom of the fill plug.
• Shifter Linkage: Ensure the shifter assembly is properly lubricated and adjusted for smooth throws.
• Break-in Period (for rebuilt units): If you’ve purchased a rebuilt T5, follow the rebuilder’s recommendations for a break-in period, which usually involves gentle driving for the first few hundred miles.
• Regular Fluid Changes: Like engine oil, transmission fluid degrades over time. Consult your Jeep’s service manual or a T5 specific guide for recommended intervals, typically every 30,000 to 50,000 miles, especially if you drive in demanding conditions.
• Avoid Overloading: The T5 is not designed for extreme torque loads. Avoid aggressive shifting, heavy towing beyond vehicle limits, or prolonged high-stress situations (e.g., trying to crawl large obstacles with oversized tires without proper gearing).

Potential Challenges and Solutions

While the T5 can be a good fit for certain applications, it’s not without its challenges:

• Weakness for Heavy Off-Roading:
  • Challenge: The T5’s aluminum case and internal components are not as robust as transmissions like the AX-15 or NV3550, making it prone to failure under aggressive off-road conditions, large tire sizes, or powerful engine swaps.
  • Solution: If heavy off-roading is your primary goal, consider upgrading to a stronger transmission. If sticking with the T5, drive it gently, use appropriate gearing, and avoid shock loads.
• Parts Availability:
  • Challenge: While some common wear items are available, finding specific internal parts for older T5 variations can be difficult.
  • Solution: Consult specialized transmission shops or online parts suppliers that deal with vintage transmission components. Sometimes, a core unit can be scavenged for hard-to-find parts.
• Identifying WC vs. NWC:
  • Challenge: Misidentifying your T5 can lead to using the wrong fluid, resulting in premature wear and failure.
  • Solution: Thoroughly research identification methods (case markings, input bearing retainer, fluid type history) or consult a knowledgeable transmission specialist. When in doubt, assume NWC and use GL-4, or drain and inspect the existing fluid for color/smell.
• Noise/Grinding:
  • Challenge: Common symptoms of worn synchronizers or bearings.
  • Solution: A rebuild is usually the best course of action. If buying used, avoid units with these symptoms unless you plan for an immediate rebuild.

Estimated Price Guide for T5 Jeep Transmissions (For Sale)

The price of a T5 Jeep transmission can vary wildly depending on its condition, whether it’s a World Class or Non-World Class unit, and the seller. This table provides a representative price range and should be used as a general guide. Always verify the specifics with the seller.

| Condition/Type | Estimated Price Range (USD) | Notes/Considerations
